CASTORS | WHEELS | ADJUSTABLE FEET PRODUCT GUIDE ISSUE 4 PRODUCT GUIDE “No one knows more about keeping your world turning than we do.”
Making The Right Choice............................................. 4 Introduction .................................................................. 2 Castor/Wheel Symbols................................................ 3 How to Choose the Correct Castor and Wheel........... 5 Castor Mounting........................................................... 6 1 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 Contents P7 CASTORS Furniture Castors ......................................................... 7 Medical Castors .......................................................... 8 Heavy Duty Twin Wheel Castors ................................. 9 Gate Castors ............................................................... 11 Designer Castors ........................................................ 12 Light Duty Castors ............................................................13 Shower Chair Castors ................................................. 17 Institutional Castors ..................................................... 18 Heavy Institutional Castors ......................................... 20 Industrial Castors ........................................................ 28 Heavy Industrial Castors ............................................. 34 Low Profile Heavy Duty Castors ................................. 40 Heavy Duty Castors .................................................... 42 Extra Heavy Duty Castors ........................................... 45 Stainless Steel Castors ............................................... 52 Stainless Steel Bolt Hole Castors ............................... 56 Industrial Waste Bin Castors ....................................... 60 Scaffold Castors .......................................................... 62 Low/High Temperature Castors -300C to +1500C ..... 63 Low/High Temperature Castors -400C to +2800C ..... 64 Low/High Temperature Castors -400C to +3000C ..... 65 Low/High Temperature Castors -400C to +4000C ..... 66 Pneumatic Castors ...................................................... 67 Solid Rubber Castors .................................................. 68 Threaded Tube Inserts ................................................ 69 Expanding Adaptors ................................................... 71 P72 P94 WHEELS Urethane Wheels ......................................................... 83 Pneumatic Wheels ...................................................... 86 Flat Free Wheels ......................................................... 90 Urethane & Nylon Rollers ............................................ 93 Solid Rubber Wheels .................................................. 74 Nylon Wheels .............................................................. 75 Wide Polyprop Wheels ................................................ 76 Low / High Temperature Wheels ................................. 77 Rubber Wheels ............................................................ 78 Cast Iron Wheels ......................................................... 80 V-Groove and Flange Wheels ..................................... 81 Urethane Wheels ......................................................... 82 Zero Pressure Wheels .................................................. 73 LEVELLING FEET Adjustable Levelling Feet ............................................ 95 A-Justa-Foot ................................................................ 98
2 www.alliedindustrial.com.au Introduction The masters of castors in New South Wales … Allied Industrial Products is dedicated to excellent service and the delivery of the highest quality products from a diverse range of quality castors, wheels, and materials handling equipment, at unbeatable prices. We have a comprehensive range of castors and wheels such as institutional castors, hospital equipment, stainless steel castors, industrial castors, heavy duty castors, scaffold castors, and so much more. Whether you're looking for fixed or swivel castors with plastic, rubber, urethane, cast iron or nylon wheels for trolleys, furniture, heavy industry or even your home BBQ - you've come to the right place. We also supply wheels and tyres for wheelchairs, wheelbarrows, mobility scooters, boat rollers, trailer jockey's, and trailers – Allied Industrial Products offers all solutions for your rolling needs. Allied Industrial Products are also suppliers and distributors of high quality Blickle and A-Justa-Foot products and, in addition, we stock a wide range of warehouse and store trolleys, handtrucks and pallet trucks. Our quick and efficient dispatch team strives to provide delivery service as soon as possible from our warehouse located in NSW, in close proximity to Sydney. We take pride in delivering your goods to you, regardless of the size of the order. It's this level of commitment, local ownership, customer support and backup that gives us the competitive edge and makes your life so much simpler! Our service is focused to your requirements from the moment you pick up the phone EASY TO ORDER, FAST AND EFFICIENT DISPATCH - Just a simple phone call and our friendly helpful sales consultants will assist you professionally and promptly. Customised Production Allied Industrial Products have the expertise and experience to produce custom made castors, wheels, handtrucks and trolleys to your specifications. Call our team to discuss your requirements and they will provide you with the best and most economical solution. It’s easier to do business with us!
3 Castor / Wheel Symbols WxD oC B/TB/S/F Wheel diameter Wheel or tyre width Hub width Bore Diameter Boss Diameter Rim diameter (pneumatic / puncture proof) Rim width Tyre diameter (pneumatic / puncture proof) Tyre/wheel material Bearing type Load per castor/wheel (load ratings are maximum for ideal conditions) Overall height Plate size Bolt hole spacing Bolt hole size Fitting Type / Size Brake/Total Brake/Swivel/Fixed Pintle Temperature Range -/+ V-Groove Width x Depth Trolley Height Toe Plate Size (Hand Trucks) Wheel Size Axle Thread swivel head race wheel brake only total braking on wheel and swivel fixed rigid plate S B TB F KG Email sales@alliedindustrial.com.au | Phone 02 9912 5105
4 www.alliedindustrial.com.au Tyre Urethane HH HHH HH HH HH Most surfaces. Grey Rubber HHH HH H HHH HH Quality flooring, quiet clean areas. Blue Rubber HHH HH H HHH HH Quality flooring, small obstructions. Black Rubber HHH HH H HH H Industrial areas, concrete. Nylon H HH HH HH HH Abrasive, industrial floors. Pneumatic HHH H H HHH HH Outdoor, irregular or unsealed. Cast Iron L HHH HHH L HHH Oven floors, outdoors or unsealed. Shock Absorbency Capacity Push Effort Floor Protection Durability Typical Surfaces When choosing the correct castor or wheel, the following points are to be considered: LOAD What is the maximum load each castor will carry? l What is the weight of the trolley l Always allow for a good safety margin - 25% l FLOOR/GROUND CONDITIONS Is the surface rough or smooth? l Are there any steps or obstacles? l HHH Excellent HH Good H Fair L Poor Wheel Selection Guide - The larger the wheel diameter the less effort required to move. DISTANCE OF TRAVEL Will the trolley be pushed long distances frequently or is it stationary for long periods? SPECIAL CONDITIONS Wet areas l High temperatures l Corrosion l Our staff are happy to answer any queries you might have. Making the Right Choice
5 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 How to Choose the Correct Castor and Wheel environment. Polyurethane and thermoplastic rubber l Divide this by the number of castors that will be On Floor Surface l Generally a soft tread rolls better on a hard floor and a l Ensure that the wheel is large enough to pass over l Harder treads require less effort to start the wheel Many varying and individual factors must be balanced to make a castor selection that will do the best job for you therefore there is no simple formula or rule that can be followed in selecting the proper castors. However AIP have put together some broad guidelines that should be useful when making your castor selection. l Domed tread wheels require less force to roll especially l Add together the maximum expected load for the hard tread rolls better on soft floors. Choosing The Castor Wheel Based Allied Industrial Products aka AIP masters of castors offers many different types and styles of castors and wheels. Our castor products are available in various specifications and combinations and are available in general duty, medium duty, and heavy duty capacities cracks and obstructions. effort over rough ground high resilience treads are best. (TPR) are virtually impervious to most solvents and Calculating The Castor Load Rating turning on smooth surfaces. For sustained lower push attached prevent damage to floors at high load ratings. chemicals. floors as they resists particle embedment. l Add 20-30% to the load as a safety margin Nylon or polyurethane treads are more suitable for dirty equipment and the weight of the equipment itself on carpeting. Flat profiles tend to spread the load and l Natural rubber is not recommended in corrosive Choosing The Castor Wheel Diameter l As a rule of thumb, the larger the wheel, the easier it is to push and to pass over bumps and minimize vibration. Roller Bearings are not suitable for high speed Choosing The Castor Bearing/Bush Type l Ball Bearings are used in applications where heat can build up due to friction. Ball bearings offer the lowest- friction and therefore the lowest push-effort. l Roller Bearings are used in high-impact applications. environments. Plain bushes are also used to reduce cost. Choosing The Type Of Brake & Castor Configuration Each arrangement offers its own advantages and performance qualities. l 4 Swivel - Maximum maneuverability. Can be moved (more than 6 km/h). l Plain Polymer bushes are used in corrosive back & forth and sideways. Perfect for confined spaces. l 2 Swivel 2 Fixed or DL - Good maneuverability except in confined spaces (cannot move sideways). l 4 Swivel 2 Fixed - High maneuverability. Can be turned narrow tubes only. threaded tube end. l Plate Mount for equipment that has a smooth flat base threaded hole (such as a nut welded into tube) or a of round, square tube sizes. applications that involve long distances or high in own length but not moved sideways. - Expanding Adaptors Suitable for installing into tubular legs for wheel diameters up to 125mm. - Grip Neck & Friction Stems Available to suit very - Solid Pintles Ideal for large diameter wheels & - Pintle Bolts Used when screwing directly into a l Bolt Hole Mount fitted by a stem of some sort. - Threaded Tube Ends Available to suit a wide range Choosing Castor Fittings Castors are generally mounted to a piece of equipment in one of two ways: such as a sheet of wood or steel. vibration.
6 www.alliedindustrial.com.au • Make sure castor load is divided over 3 • Maximum manouvreability. 3 Swivel Castors castors rather than the normal 4 4 Swivel Castors • Can be moved at right angles • Maximum manouvreability in confined spaces • Difficult to control on long runs • Limited manouvreability in confined spaces • Inexpensive • Most practical 2 Swivel Castors and 2 Fixed Castors • Good for straight or long distances and 2 Swivel Castors • Good manouvreability Tilt Mount Rocking Type 2 Fixed Wheels • Accurate steering • Cannot negotiate ramps • Level mounting design for heavy loads • Very stable 4 Swivel Castors and 2 Fixed Castors • Best for long wheelbases and straight lines It’s easier to do business with us. FAST & EFFICIENT DESPATCH Our service is focused to your requirements from the moment you pick up the phone. EASY TO ORDER Just a simple phone call and our friendly helpful sales consultants will assist you professionally and promptly. www.alliedindustrial.com.au Castor Mounting
7 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 Furniture Castors An economic and attractive twin wheel hooded design is perfect for DIY fitting and returning rolling functionality to your furniture - Furniture Castors and easily rolling l Suited for office furniture, chairs, cabinets l Available with a range of fittings to suit your and light trolleys application these castors are hard wearing TW50-U16-B TW50-S TW50-38 TW50-C11-B TW50-P Wheel Overall Diameter Wheel Load per Height Printle (mm) Material Castor (mm) Type TW50-U16 50 Nylon 40kg 65 U bracket 16mm TW50-U16-B 50 Nylon 40kg 65 U bracket 16mm TW50-U18 50 Nylon 40kg 65 U bracket 18mm TW50-U18-B 50 Nylon 40kg 65 U bracket 18mm TW50-U25 50 Nylon 40kg 65 U bracket 25mm TW50-U25-B 50 Nylon 40kg 65 U bracket 25mm TW50-C11 50 Nylon 40kg 65 Circlip 11mm TW50-38 50 Nylon 40kg 65 3/8” BSW TW50-S-B 50 Nylon 40kg 65 Stem + Socket TW50-516 50 Nylon 40kg 65 5/16”x19 BSW TW50-S 50 Nylon 40kg 65 Stem + Socket TW50-C11-B 50 Nylon 40kg 65 Circlip 11mm TW50-C11(OC) 50 Nylon 40kg 65 Circlip 11mm TW50-516-B 50 Nylon 40kg 65 5/16”x19 BSW TW50-P 50 Nylon 40kg 65 Plate 38x38mm TW50-38-B 50 Nylon 40kg 65 3/8” BSW TW50-P-B 50 Nylon 40kg 65 Plate 38x38mm
8 www.alliedindustrial.com.au Medical Castors - Medical Castors Features ball bearing headrace with outer bearing seals ensuring smooth swivelling action and long life l Attractive twin wheel design with urethane wheels for shock absorbency and non- marking qualities l Strong and durable with sealed ball bearings in medical and institutional applications l Smooth and quiet running developed for use UTW75-M12 UTW100-P UTW100-M12-B Wheel Wheel Overall (mm) (mm) Material Castor Type (mm) Type Diameter Width Wheel Load per Bearing Height Printle UTW75-M12-B 75 2x12 Urethane 70kg Ball 95 M12x20 UTW50-M12-B 50 2x12 Urethane 50kg Plain 60 M12x20 UTW50-M12 50 2x12 Urethane 50kg Plain 60 M12x20 UTW75-M12 75 2x12 Urethane 70kg Ball 95 M12x20 UTW75-P 75 2x12 Urethane 70kg Ball 106 70x58 UTW100-M12 100 2x12 Urethane 100kg Ball 138 M12x25 UTW100-M12-B 100 2x12 Urethane 100kg Ball 138 M12x25 UTW100-P 100 2x12 Urethane 100kg Ball 138 70x58 UTW100-P-B 100 2x12 Urethane 100kg Ball 138 70x58 UTW75-P-B 75 2x12 Urethane 70kg Ball 106 70x58
9 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 Heavy Duty Twin Wheel Castors - Rubber Wheels Features double ball bearing headrace with outer seals ensuring smooth swivelling action and long life l Twin rubber wheels for shock absorbing and l Strong and durable with polyprop centres equipment, medical, shops and general l For loads up to 90kg non-marking qualities and sealed ball bearings l Smooth and quiet running suited for mobile industry ATR50/P ATR75/P-TB ATR75/P F P P-TB Wheel Wheel Overall Swivel Plate Bolt Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) ATR50/P-TB 50 2x20 Rubber 70kg Ball 72 TB 60x60 38x38 ATR75/P 75 2x25 Rubber 90kg Ball 101 S 77x67 55x48 ATR75/P-TB 75 2x25 Rubber 90kg Ball 101 TB 77x67 55x48 ATR50/P 50 2x20 Rubber 70kg Ball 72 S 60x60 38x38 F Fixed P Swivel P-TB Swivel Total Brake BRACKET KEY
Heavy Duty Twin Wheel Castors - Rubber Wheels Features double ball bearing headrace with outer seals ensuring smooth swivelling action and long life non-marking qualities and sealed ball bearings industry l For loads up to 90kg l Twin rubber wheels for shock absorbing and l Strong and durable with polyprop centres l Smooth and quiet running suited for mobile equipment, medical, shops and general ATR50/H ATR75/H-TB ATR75/H H H H-TB Wheel Wheel Overall Swivel Bolt Hole (mm) (mm) Material Castor Type (mm) (mm) Diameter Width Wheel Load per Bearing Height Total Brake Spacing ATR50/H 50 2x20 Rubber 70kg Ball 72 S 10 ATR50/H-TB 50 2x20 Rubber 70kg Ball 72 TB 10 ATR75/H-TB 75 2x25 Rubber 90kg Ball 99 TB 10/12 ATR75/H 75 2x25 Rubber 90kg Ball 99 S 10/12 10 www.alliedindustrial.com.au H Swivel H-TB Total Brake REFER TO PAGE 69-71 FOR TUBE FITTING BRACKET KEY
11 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 - Rubber/Nylon Wheels Features double ball bearing headrace ensuring smooth swivelling action and long life Rubber wheels for shock absorbing and nonmarking qualities, Nylon wheels for hard wearing l The spring loaded design provides shock absorption features specifically for use on uneven surfaces and mounting is integrated into the frame of the castor for easy fixing to l Suited for residential/commercial gates l For loads up to 55kg any gate system GC50 GSL100 GSL50/P Wheel Wheel Overall Swivel Plate Bolt Diameter Width Wheel Load per Bearing Height Total Braked Mount Spacing (mm) (mm) Material Castor Type (mm) Size (mm) (mm) Gate Castors GC50 50 20 Nylon 40kg Plain 75 F 40x30 2x 8mm holes GSL50/F 50 20 Rubber 50kg Ball 155 F 60x49 45x39 GSL50/P 50 20 Rubber 50kg Ball 155 S 60x49 45x39 GSL100 100 25 Rubber 55kg Plain 265 S 100x25 2x 8mm holes
12 www.alliedindustrial.com.au Designer Castors F Fixed P Swivel P-TB Swivel Total Brake Wheel Wheel Overall Swivel Bolt Diameter Width Wheel Load per Bearing Height Plate Size Spacing (mm) (mm) Material Castor Type (mm) Braked (mm) (mm) Wheel Overall Pintle (mm) Material Castor Type (mm) Diameter Wheel Load per Bearing Height Type ALPU75/P-B 75 23 Urethane 50kg Plain 92 B 50x50 38x38 ALPU75/P 75 23 Urethane 50kg Plain 92 S 50x50 38x38 WCU100/C11 100 Urethane 50kg Plain 120 Circlip 11mm Features double ball bearing headrace ensuring smooth swivelling action and long life - Urethane Wheels - Urethane Wheels Features double ball bearing headrace ensuring smooth swivelling action and long life l Attractive Clear Urethane wheels for hard wearing and non-marking qualities l Smooth and quiet running suited for shop displays, office furniture and home use l For loads up to 50kg l For loads up to 50kg l Urethane wheels for hard wearing and nonl Smooth and quiet running suited for mobile equipment, medical and Rubbermaid trolleys marking qualities ALPU75/P F ALPU75/P-B P WCU100-C11 BRACKET KEY
13 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 Light Duty Castors LLN50/F LLN100/P-TB LLN50/P Nylon wheels for hard wearing and nonmarking qualities. - White Nylon Wheels Features double ball bearing headrace ensuring smooth swivelling action and long life l Smooth and quiet running suited for light trolleys, furniture and home use l Strong and durable l For loads up to 80kg F Fixed P Swivel P-TB Swivel Total Brake F P P-TB ALN30/P 32 14 White Nylon 20kg Plain 42 S 38x32 30x24 LLN75/P 75 25 White Nylon 60kg Plain 100 S 60x60 43x43 LLN100/P-TB 100 24 White Nylon 80kg Plain 134 TB 76x76 55x55 ILN65/P 65 25 White Nylon 55kg Plain 80 S 70x58 55x42 ILN50/F 50 21 White Nylon 40kg Plain 65 F 58x40 45x25 ILN50/P-B 50 21 White Nylon 40kg Plain 65 B 59x47 46x35 LLN100/F 100 27 White Nylon 80kg Plain 134 F 76x76 55x55 ALN40/P 40 20 White Nylon 30kg Plain 57 S 52x31 40x21 LLN50/F 50 20 White Nylon 40kg Plain 69 F 60x60 43x43 LLN50/P-TB 50 20 White Nylon 40kg Plain 69 TB 60x60 43x43 ILN65/F 65 25 White Nylon 55kg Plain 80 F 70x47 55x28 ILN65/P-B 65 25 White Nylon 55kg Plain 80 B 70x58 55x42 ILN50/P 50 21 White Nylon 40kg Plain 65 S 59x47 46x35 LLN50/P 50 20 White Nylon 40kg Plain 69 S 60x60 43x43 LLN75/F 75 25 White Nylon 60kg Plain 100 F 60x60 43x43 LLN75/P-TB 75 25 White Nylon 60kg Plain 100 TB 60x60 43x43 LLN100/P 100 27 White Nylon 80kg Plain 134 S 76x76 55x55 Wheel Wheel Overall Swivel Plate Bolt Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) BRACKET KEY
14 www.alliedindustrial.com.au Light Duty Castors - Rubber Wheels Features double ball bearing headrace with outer bearing seals ensuring smooth swivelling action and long life duty trolleys, furniture and home use absorbency and non-marking qualities l Grey/Black rubber wheels for shock l Strong and durable with polyprop centres and sealed ball bearings l For loads up to 80kg l Smooth and quiet running suited for light LLR50/F LLR100/P-TB LLR75/P F P P-TB F Fixed P Swivel P-TB Swivel Total Brake LLR50/P 50 20 Grey Rubber 40kg Ball 69 S 60x60 43x43 LLR50/P-TB 50 20 Grey Rubber 40kg Ball 69 TB 60x60 43x43 LLR50/F 50 20 Grey Rubber 40kg Ball 69 F 60x60 43x43 ALR50/P 50 25 Grey Rubber 50kg Ball 72 S 50x50 38x38 ALR50/P-TB 50 25 Grey Rubber 50kg Ball 72 TB 50x50 38x38 ILR65/F 65 25 Black Rubber 55kg Plain 80 F 70x47 55x28 ILR65/P 65 25 Black Rubber 55kg Plain 80 S 70x58 55x42 ILR65/P-B 65 25 Black Rubber 55kg Plain 80 B 70x58 55x42 ALR65/F 65 25 Grey Rubber 60kg Ball 93 F 72x60 55x42 ALR65/P 65 25 Grey Rubber 60kg Ball 93 S 72x60 55x42 LLR75/F 75 25 Grey Rubber 60kg Ball 100 F 60x60 43x43 LLR75/P-TB 75 25 Grey Rubber 60kg Ball 100 TB 60x60 43x43 LLR100/P 100 27 Grey Rubber 80kg Ball 134 S 76x76 55x55 LLR100/P-TB 100 27 Grey Rubber 80kg Ball 134 TB 76x76 55x55 ALR65/P-TB 65 25 Grey Rubber 60kg Ball 93 TB 72x60 55x42 LLR75/P 75 25 Grey Rubber 60kg Ball 100 S 60x60 43x43 LLR100/F 100 27 Grey Rubber 80kg Ball 134 F 76x76 55x55 Wheel Wheel Overall Swivel Plate Bolt (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing BRACKET KEY
15 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 Light Duty Castors - Urethane Wheels Features double ball bearing headrace with outer bearing seals ensuring smooth swivelling action and long life. - Cast Iron Wheels Features single ball bearing headrace ensuring smooth swivelling action and long life l Urethane wheels for hard wearing and non- l Strong and durable with solid nylon centres and sealed ball bearings l For loads up to 60kg marking qualities l Smooth and quiet running suited for light duty trolleys, furniture and home use uses l For loads up to 40kg l Cast iron wheels for hard wearing l Strong and durable with solid centres l Suited for light duty trolleys, light industrial ALU50/F ALU50/P-B ALU50/P F P P-B F Fixed P Swivel P-TB Swivel Total Brake ALU50/F 50 20 Grey Urethane 40kg Plain 65 F 58x40 45x25 ILU50/P-B 50 25 Black Urethane 60kg Ball 70 B 71x55 53x36 ALU65/P 65 25 Grey Urethane 60kg Plain 86 S 70x58 55x42 ALU65/F 65 25 Grey Urethane 60kg Plain 86 F 70x47 55x28 ALU50/P-B 50 20 Grey Urethane 40kg Plain 65 B 59x47 46x35 ILU50/P 50 25 Black Urethane 60kg Ball 70 S 71x55 53x36 ILU50/F 50 25 Black Urethane 60kg Ball 70 F 71x55 53x36 ALU50/P 50 20 Grey Urethane 40kg Plain 65 S 59x47 46x35 Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing Wheel Wheel Overall Swivel Plate Bolt (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) LLI50/F 50 22 Cast Iron 40kg Plain 64 F 58x40 43x23 LLi50/P 50 22 Cast Iron 40kg Plain 64 S 58x48 46x35 (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) Wheel Wheel Overall Swivel Plate Bolt Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing F LLI50/F P LLI50/P BRACKET KEY
16 www.alliedindustrial.com.au Light Duty Castors - Rubber Wheels Features double ball bearing headrace with outer bearing seals ensuring smooth swivelling action and long life - Urethane Wheels Features double ball bearing headrace with outer bearing seals ensuring smooth swivelling action and long life l For loads up to 60kg l Grey rubber wheels for shock absorbency and non-marking qualities l Smooth and quiet running suited for light l Strong and durable with polyprop centres and sealed ball bearings duty trolleys, furniture and home use l Smooth and quiet running suited for light duty trolleys, furniture and home use l For loads up to 40kg l Strong and durable with polyprop centres l Urethane wheels for hard wearing and non- marking qualities LLR50/H ALR100/H-TB H ALU50/H H ALR65/H H ALU50/H-B H-B H-TB (mm) (mm) Material Castor Type (mm) (mm) Size Diameter Width Wheel Load per Bearing Height Total Brake Hole Wheel Wheel Overall Swivel Bolt LLR50/H-TB 50 20 Grey Rubber 40kg Ball 68 TB 10 LLR50/H 50 20 Grey Rubber 40kg Ball 68 S 10 ALR65/H-TB 65 25 Grey Rubber 60kg Ball 93 TB 10 ALR65/H 65 25 Grey Rubber 60kg Ball 93 S 10 ALR50/H 50 25 Grey Rubber 50kg Ball 72 S 10 ALR50/H-TB 50 25 Grey Rubber 50kg Ball 72 TB 10 ALR100/H-TB 100 25 Grey Rubber 60kg Ball 134 TB 12 ALR100/H 100 25 Grey Rubber 60kg Ball 134 S 12 Wheel Wheel Overall Swivel Bolt (mm) (mm) Material Castor Type (mm) (mm) Diameter Width Wheel Load per Bearing Height Total Brake Hole ALU50/H 50 20 Urethane 40 Plain 67 S 10 ALU50/H-B 50 20 Urethane 40 Plain 67 B 10 REFER TO PAGE 69-71 FOR TUBE FITTING H Swivel H-TB Total Brake BRACKET KEY
17 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 Features double ball bearing headrace with inner and outer seals ensuring smooth swivelling action and long life - Rubber Wheels l Grey rubber wheels for shock absorbency l Strong and durable with polyprop centres and sealed ball bearings l Smooth and quiet running suited for mobile equipment, medical, shops and general and non-marking qualities industry l For loads up to 100kg ASR125/NH H ASR125/NH-TB H-TB Diameter Width Wheel Load per Bearing Height Total Brake Hole Wheel Wheel Overall Swivel Bolt (mm) (mm) Material Castor Type (mm) Fixed Size Shower Chair Castors ASR125/NH 125 32 Grey Rubber 100kg Ball 165 H 10/12 ASR125/NH-TB 125 32 Grey Rubber 100kg Ball 165 TB 10/12 REFER TO PAGE 69-71 FOR TUBE FITTING H Swivel H-TB Total Brake BRACKET KEY
18 www.alliedindustrial.com.au Rubber wheels for shock absorbing and nonmarking qualities Features double ball bearing headrace ensuring smooth swivelling action and long life - Rubber Wheels industry l For loads up to 100kg and sealed ball bearings equipment, medical, shops and general l Smooth and quiet running suited for mobile l Strong and durable with polyprop centres HLR125/F HLR125/P-TB HLR100/P F P P-TB F Fixed P Swivel P-TB Swivel Total Brake (mm) (mm) Material Castor Type (mm) Fixed Size Size Wheel Wheel Overall Swivel Bolt Diameter Width Wheel Load per Bearing Height Total Brake Plate Hole Institutional Castors HLR75/P 75 30 Rubber 80kg Ball 100 S 76x67 55x48 HLR75/F 75 30 Rubber 80kg Ball 100 F 76x67 55x48 HLR75/P-DB 75 30 Rubber 80kg Ball 100 DB 76x67 55x48 HLR100/P-TB 100 30 Rubber 100kg Ball 132 TB 76x67 55x48 HLR100/P-DB 100 30 Rubber 100kg Ball 132 DB 76x67 55x48 HLR125/P-TB 125 30 Rubber 100kg Ball 161 TB 76x67 55x48 HLR125/P-DB 125 30 Rubber 100kg Ball 161 DB 76x67 55x48 HLR100/P 100 30 Rubber 100kg Ball 132 S 76x67 55x48 HLR125/F 125 30 Rubber 100kg Ball 161 F 76x67 55x48 HLR75/P-TB 75 30 Rubber 80kg Ball 100 TB 76x67 55x48 HLR125/P 125 30 Rubber 100kg Ball 161 S 76x67 55x48 HLR100/F 100 30 Rubber 100kg Ball 132 F 76x67 55x48 BRACKET KEY
19 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 - Rubber Wheels Features double ball bearing headrace ensuring smooth swivelling action and long life Grey rubber wheels for shock absorbency and non-marking qualities l Strong and durable with polyprop centres l Smooth and quiet running suited for mobile equipment, medical, shops and general industry l For loads up to 100kg and sealed ball bearings HLR75/H HLR125/H HLR100/H-TB H H-TB H Wheel Wheel Overall Swivel Bolt (mm) (mm) Material Castor Type (mm) Fixed Size Diameter Width Wheel Load per Bearing Height Total Brake Hole Institutional Castors HLR75/H-DB 75 30 Grey Rubber 80kg Ball 100 DB 10/12 HLR100/H-TB 100 30 Grey Rubber 100kg Ball 132 TB 10/12 HLR75/H-DB 100 30 Grey Rubber 100kg Ball 132 DB 10/12 HLR125/H 125 30 Grey Rubber 100kg Ball 161 H 10/12 HLR100/H 100 30 Grey Rubber 100kg Ball 132 H 10/12 HLR75/H-TB 75 30 Grey Rubber 80kg Ball 100 TB 10/12 HLR75/H-DB 125 30 Grey Rubber 100kg Ball 161 DB 10/12 HLR75/H 75 30 Grey Rubber 80kg Ball 100 H 10/12 HLR125/H-TB 125 30 Grey Rubber 100kg Ball 161 TB 10/12 REFER TO PAGE 69-71 FOR TUBE FITTING H Swivel H-TB Total Brake BRACKET KEY
20 www.alliedindustrial.com.au - Nylon Wheels Features double ball bearing headrace with outer seals ensuring smooth swivelling action and long life equipment, medical, shops and general industry marking qualities l Strong and durable l Nylon wheels for hard wearing and nonl For loads up to 100kg l Smooth and quiet running suited for mobile LCN75/F-B LCN100/P-TB LCN100/P-B F P P-TB F Fixed P Swivel P-TB Swivel Total Brake LCN75/F-B 75 32 Black Nylon 80kg Plain 111 F 95x67 73x45 LCN100/P-B 100 32 Black Nylon 100kg Plain 135 S 95x67 73x45 LCN75/P-B 75 32 Black Nylon 80kg Plain 111 S 95x67 73x45 LCN100/P-TB-B 100 32 Black Nylon 100kg Plain 135 TB 95x67 73x45 LCN100/F-B 100 32 Black Nylon 100kg Plain 135 F 95x67 73x45 LCN75/P-TB-B 75 32 Black Nylon 80kg Plain 111 TB 95x67 73x45 Wheel Wheel Overall Swivel Plate Bolt (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing Heavy Institutional Castors BRACKET KEY
21 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 Heavy Institutional Castors Features double ball bearing headrace with outer seals ensuring smooth swivelling action and long life - Rubber Wheels non-marking qualities l Strong and durable with polyprop centres and sealed ball bearings industry l For loads up to 150kg l Smooth and quiet running suited for mobile equipment, medical, shops and general l Rubber wheels for shock absorbing and F Fixed P Swivel P-TB Swivel Total Brake LCR100/P-TB 100 32 Rubber 100kg Ball 135 TB 95x67 73x45 LCR75/P 75 32 Rubber 80kg Ball 111 S 95x67 73x45 LCR125/F 125 32 Rubber 150kg Ball 162 F 95x67 73x45 LCR75/P-TB 75 32 Rubber 80kg Ball 111 TB 95x67 73x45 LCR100/P 100 32 Rubber 100kg Ball 135 S 95x67 73x45 LCR125/P 125 32 Rubber 150kg Ball 162 S 95x67 73x45 LCR100/F 100 32 Rubber 100kg Ball 135 F 95x67 73x45 LCR75/F 75 32 Rubber 80kg Ball 111 F 95x67 73x45 LCR125/P-TB 125 32 Rubber 150kg Ball 162 TB 95x67 73x45 Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing Wheel Wheel Overall Swivel Plate Bolt (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) LCR75/F LCR125/P-TB LCR100/P F P P-TB BRACKET KEY
22 www.alliedindustrial.com.au Heavy Institutional Castors Features double ball bearing headrace with outer seals ensuring smooth swivelling action and long life - Blue Rubber Wheels l Rubber wheels for shock absorbing and l Strong and durable with polyprop centres non-marking qualities and sealed ball bearings l Smooth and quiet running suited for mobile equipment, medical, shops and general industry l For loads up to 100kg LCB75/F LCB75/P-TB LCB100/P F P P-TB F Fixed P Swivel P-TB Swivel Total Brake LCB75/F 75 32 Blue Rubber 80kg Ball 111 F 95x67 73x45 LCB75/P 75 32 Blue Rubber 80kg Ball 111 S 95x67 73x45 LCB75/P-TB 75 32 Blue Rubber 80kg Ball 111 TB 95x67 73x45 LCB100/F 100 32 Blue Rubber 100kg Ball 135 F 95x67 73x45 LCB100/P 100 32 Blue Rubber 100kg Ball 135 S 95x67 73x45 LCB100/P-TB 100 32 Blue Rubber 100kg Ball 135 TB 95x67 73x45 (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) Wheel Wheel Overall Swivel Plate Bolt Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing BRACKET KEY
23 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 Heavy Institutional Castors Features double ball bearing headrace with outer seals ensuring smooth swivelling action and long life - Urethane Wheels l Smooth and quiet running suited for mobile l Urethane wheels for hard wearing and non- marking qualities l For loads up to 180kg l Strong and durable with polyprop centres and sealed ball bearings equipment, medical, shops and general industry LCU75/F LCU125/P-TB LCU100/P F P P-TB F Fixed P Swivel P-TB Swivel Total Brake LCU125/P 125 32 Urethane 180kg Ball 162 S 95x67 73x45 LCU75/F 75 32 Urethane 100kg Ball 111 F 95x67 73x45 LCU100/P-TB 100 32 Urethane 150kg Ball 135 TB 95x67 73x45 LCU75/P 75 32 Urethane 100kg Ball 111 S 95x67 73x45 LCU75/P-TB 75 32 Urethane 100kg Ball 111 TB 95x67 73x45 LCU100/F 100 32 Urethane 150kg Ball 135 F 95x67 73x45 LCU125/F 125 32 Urethane 180kg Ball 162 F 95x67 73x45 LCU125/P-TB 125 32 Urethane 180kg Ball 162 TB 95x67 73x45 LCU100/P 100 32 Urethane 150kg Ball 135 S 95x67 73x45 Wheel Wheel Overall Swivel Plate Bolt (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing BRACKET KEY
24 www.alliedindustrial.com.au Features double ball bearing headrace with outer bearing seals ensuring smooth swivelling action and long life - Nylon Wheels l industry marking qualities l Smooth and quiet running suited for mobile l Nylon wheels for hard wearing and non- l For loads up to 150kg l Strong and durable equipment, medical, shops and general LCN75/H-B LCN100/H-TB-B LCN100/H-B H H H-TB LCN100/H-B 100 32 Black Nylon 100kg Ball 133 H 10/12 LCN100/H-TB-B 100 32 Black Nylon 100kg Ball 133 TB 10/12 LCN75/H-B 75 32 Black Nylon 80kg Ball 109 H 10/12 LCN75/H-TB-B 75 32 Black Nylon 80kg Ball 109 TB 10/12 Wheel Wheel Overall Swivel Bolt Diameter Width Wheel Load per Bearing Height Total Brake Hole (mm) (mm) Material Castor Type (mm) Fixed Size Heavy Institutional Castors REFER TO PAGE 69-71 FOR TUBE FITTING H Swivel H-TB Total Brake BRACKET KEY
25 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 - Rubber Wheels Features double ball bearing headrace with outer bearing seals ensuring smooth swivelling action and long life and non-marking qualities equipment, medical, shops and general l Grey rubber wheels for shock absorbency l Smooth and quiet running suited for mobile l Strong and durable with polyprop centres and sealed ball bearings l For loads up to 150kg industry LCR75/H LCR125/H LCR100/H-TB H H-TB H Wheel Wheel Overall Swivel Bolt Diameter Width Wheel Load per Bearing Height Total Brake Hole (mm) (mm) Material Castor Type (mm) Fixed Size Heavy Institutional Castors LCR100/H-TB 100 32 Grey Rubber 100kg Ball 133 TB 10/12 LCR125/H 125 32 Grey Rubber 150kg Bal l160 H 10/12 LCR125/H-TB 125 32 Grey Rubber 150kg Ball 160 TB 10/12 LCR75/H 75 32 Grey Rubber 80kg Ball 109 H 10/12 LCR100/H 100 32 Grey Rubber 100kg Ball 133 H 10/12 LCR75/H-TB 75 32 Grey Rubber 80kg Ball 109 TB 10/12 REFER TO PAGE 69-71 FOR TUBE FITTING H Swivel H-TB Total Brake BRACKET KEY
26 www.alliedindustrial.com.au Heavy Institutional Castors - Blue Rubber Wheels Features double ball bearing headrace with outer bearing seals ensuring smooth swivelling action and long life l Smooth and quiet running suited for mobile l Blue rubber wheels for shock absorbency and non-marking qualities and sealed ball bearings equipment, medical, shops and general industry l Strong and durable with polyprop centres l For loads up to 150kg LCB75/H-TB 75 32 Blue Rubber 80kg Ball 109 TB 10/12 LCB125/H-TB 125 32 Blue Rubber 150kg Ball 160 TB 10/12 LCB100/H 100 32 Blue Rubber 100kg Ball 133 H 10/12 LCB100/H-TB 100 32 Blue Rubber 100kg Ball 133 TB 10/12 LCB75/H 75 32 Blue Rubber 80kg Ball 109 H 10/12 LCB125/H 125 32 Blue Rubber 150kg Ball 160 H 10/12 Wheel Wheel Overall Swivel Bolt Diameter Width Wheel Load per Bearing Height Total Brake Hole (mm) (mm) Material Castor Type (mm) Fixed Size LCB75/H LCB100/H LCB100/H-TB H H-TB T REFER TO PAGE 69-71 FOR TUBE FITTING H Swivel H-TB Total Brake BRACKET KEY
27 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 Heavy Institutional Castors - Urethane Wheels Features double ball bearing headrace with outer bearing seals ensuring smooth swivelling action and long life industry l Smooth and quiet running suited for mobile l Urethane wheels for hard wearing and non- marking qualities l Strong and durable with polyprop centres equipment, medical, shops and general l For loads up to 180kg and sealed ball bearings LCU75/H LCU125/H LCU100/H-TB H H-TB H LCU75/H-TB 75 32 Grey Rubber 100kg Ball 109 TB 10/12 LCU100/H 100 32 Grey Rubber 150kg Ball 133 H 10/12 LCU100/H-TB 100 32 Grey Rubber 150kg Ball 133 TB 10/12 LCU125/H 125 32 Grey Rubber 180kg Ball 160 H 10/12 LCU125/H-TB 125 32 Grey Rubber 180kg Ball 160 TB 10/12 LCU75/H 75 32 Grey Rubber 100kg Ball 109 H 10/12 Diameter Width Wheel Load per Bearing Height Total Brake Hole Wheel Wheel Overall Swivel Bolt (mm) (mm) Material Castor Type (mm) Fixed Size H Swivel H-TB Total Brake REFER TO PAGE 69-71 FOR TUBE FITTING BRACKET KEY
28 www.alliedindustrial.com.au Features double ball bearing headrace with outer seals ensuring smooth swivelling action and long life - Nylon Wheels l Nylon wheels for hard wearing and nonl Strong and durable marking qualities material handling equipment l For loads up to 200kg l Smooth and quiet running suited for mobile equipment, workshops/warehouses and HCN80/F F P P-TB Industrial Castors F Fixed P Swivel P-TB Swivel Total Brake (mm) (mm) Material Castor Type (mm) Fixed Size Size Diameter Width Wheel Load per Bearing Height Total Brake Plate Hole Wheel Wheel Overall Swivel Bolt HCN80/P 80 32 White Nylon 100kg Plain 102 S 105x80 80x60 HCN80/P-TB 80 32 White Nylon 100kg Plain 102 TB 105x80 80x60 HCN80/F 80 32 White Nylon 100kg Plain 102 F 105x80 80x60 HCN100/F-B 100 32 Black Nylon 120kg Plain 125 F 105x80 80x60 HCN125/F-B 125 32 Black Nylon 200kg Plain 154 F 105x80 80x60 HCN125/P-B 125 32 Black Nylon 200kg Plain 154 S 105x80 80x60 HCN125/P-TB-B 125 32 Black Nylon 200kg Plain 154 TB 105x80 80x60 HCN100/P-TB-B 100 32 Black Nylon 120kg Plain 125 TB 105x80 80x60 HCN100/P-B 100 32 Black Nylon 120kg Plain 125 S 105x80 80x60 HCN100/P-B HCN100/P-TB-B BRACKET KEY
29 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 Features double ball bearing headrace with outer seals ensuring smooth swivelling action and long life - Blue Rubber Wheels equipment, workshops/warehouses and l For loads up to 200kg l Strong and durable with polyprop centres and bearings l Rubber wheels for shock absorbing and l Smooth and quiet running suited for mobile non-marking qualities material handling equipment HCB80/F HCB125/P-TB HCB100/P F P P-TB F Fixed P Swivel P-TB Swivel Total Brake Wheel Wheel Overall Swivel Bolt Diameter Width Wheel Load per Bearing Height Total Brake Plate Hole (mm) (mm) Material Castor Type (mm) Fixed Size Size HCB100/F 100 35 Blue Rubber 150kg Roller 125 F 105x80 80x60 HCB125/F 125 36 Blue Rubber 200kg Ball 154 F 105x80 80x60 HCB125/P-TB 125 36 Blue Rubber 200kg Ball 154 TB 105x80 80x60 HCB100/P-TB 100 35 Blue Rubber 150kg Roller 125 TB 105x80 80x60 HCB80/P-TB 80 32 Blue Rubber 100kg Roller 102 TB 105x80 80x60 HCB80/P 80 32 Blue Rubber 100kg Roller 102 S 105x80 80x60 HCB100/P 100 35 Blue Rubber 150kg Roller 125 S 105x80 80x60 HCB80/F 80 32 Blue Rubber 100kg Roller 102 F 105x80 80x60 HCB125/P 125 36 Blue Rubber 200kg Ball 154 S 105x80 80x60 Industrial Castors BRACKET KEY
30 www.alliedindustrial.com.au Industrial Castors - Urethane Wheels Features double ball bearing headrace with outer seals ensuring smooth swivelling action and long life marking qualities l For loads up to 150kg material handling equipment l Strong and durable with polyprop centres l Urethane wheels for hard wearing and non- equipment, workshops/warehouses and and roller bearings l Smooth and quiet running suited for mobile HCO100/F HCO1OO/P-TB HCO100/P F P P-TB F Fixed P Swivel P-TB Swivel Total Brake Wheel Wheel Overall Swivel Bolt Diameter Width Wheel Load per Bearing Height Total Brake Plate Hole (mm) (mm) Material Castor Type (mm) Fixed Size Size HCU125/P-TB 125 35 Red Urethane 150kg Roller 154 TB 105x80 80x60 HCO100/P-TB 100 32 Red Urethane 120kg Roller 125 TB 105x80 80x60 HCU125/F 125 35 Red Urethane 150kg Roller 154 F 105x80 80x60 HCU125/P 125 35 Red Urethane 150kg Roller 154 S 105x80 80x60 HCO80/P 80 32 Red Urethane 100kg Roller 102 S 105x80 80x60 HCO80/P-TB 80 32 Red Urethane 100kg Roller 102 TB 105x80 80x60 HCO80/F 80 32 Red Urethane 100kg Roller 102 F 105x80 80x60 HCO100/F 100 32 Red Urethane 120kg Roller 125 F 105x80 80x60 HCO100/P 100 32 Red Urethane 120kg Roller 125 S 105x80 80x60 BRACKET KEY
31 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 Industrial Castors - Nylon Wheels Features double ball bearing headrace with outer bearing seals ensuring smooth swivelling action and long life l Strong and durable equipment, workshops/warehouses and marking qualities l Nylon wheels for hard wearing and non- material handling l For loads up to 200kg l Smooth and quiet running suited for mobile HCN80/H HCN125/H HCN125/H-TB H H-TB H-TB H Swivel H-TB Total Brake Diameter Width Wheel Load per Bearing Height Total Brake Hole (mm) (mm) Material Castor Type (mm) Fixed Size Wheel Wheel Overall Swivel Bolt HCN80/H 80 32 White Nylon 100kg Plain 102 H 10/12 HCN80/H-TB 80 32 White Nylon 100kg Plain 102 TB 10/12 HCN100/H-B 100 35 Black Nylon 120kg Plain 125 H 10/12 HCN100/H-TB-B 100 35 Black Nylon 120kg Plain 125 TB 10/12 HCN125/H-TB 125 36 White Nylon 200kg Plain 154 TB 10/12 HCN125/H 125 36 White Nylon 200kg Plain 154 H 10/12 REFER TO PAGE 69-71 FOR TUBE FITTING BRACKET KEY
32 www.alliedindustrial.com.au Industrial Castors - Blue Rubber Wheels Features double ball bearing headrace with outer bearing seals ensuring smooth swivelling action and long life material handling non-marking qualities l Blue rubber wheels for shock absorbing and l Strong and durable with polyprop centres and bearings l Smooth and quiet running suited for mobile equipment, workshops/warehouses and l For loads up to 200kg HCB80/H HCB125/H HCB100/H-TB H H H-TB Wheel Wheel Overall Swivel Bolt Diameter Width Wheel Load per Bearing Height Total Brake Hole (mm) (mm) Material Castor Type (mm) Fixed Size HCB80/H 80 32 Blue Rubber 100kg Roller 102 H 10/12 HCB80/H-TB 80 32 Blue Rubber 100kg Roller 102 TB 10/12 HCB100/H 100 35 Blue Rubber 150kg Roller 125 H 10/12 HCB100/H-TB 100 35 Blue Rubber 150kg Roller 125 TB 10/12 HCB125/H-TB 125 36 Blue Rubber 200kg Ball 154 TB 10/12 HCB125/H 125 36 Blue Rubber 200kg Ball 154 H 10/12 H Swivel H-TB Total Brake REFER TO PAGE 69-71 FOR TUBE FITTING BRACKET KEY
33 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 Industrial Castors H Swivel H-TB Total Brake - Urethane Wheels Features double ball bearing headrace with outer bearing seals ensuring smooth swivelling action and long life l For loads up to 150kg l Smooth and quiet running suited for mobile material handling l Urethane wheels for hard wearing and nonl Strong and durable with polyprop centres marking qualities and roller bearings equipment, workshops/warehouses and HCO80/H HCU125/H HCO100/H-TB H H H-TB Wheel Wheel Overall Swivel Bolt Diameter Width Wheel Load per Bearing Height Total Brake Hole (mm) (mm) Material Castor Type (mm) Fixed Size HCO80/H 80 32 Red Urethane 100kg Roller 102 H 10/12 HCO100/H-TB 100 35 Red Urethane 120kg Roller 125 TB 10/12 HCO100/H 100 35 Red Urethane 120kg Roller 125 H 10/12 HCO80/H-TB 80 32 Red Urethane 100kg Roller 102 TB 10/12 HCU125/H 125 36 Red Urethane 150kg Roller 154 H 10/12 HCU125/H-TB 125 36 Red Urethane 150kg Roller 154 TB 10/12 IMAGE QUALITY? REFER TO PAGE 69-71 FOR TUBE FITTING BRACKET KEY
34 www.alliedindustrial.com.au Heavy Industrial Castors - White Nylon Wheels Features double ball bearing headrace with inner and outer bearing seals ensuring smooth swivelling action and long life l Strong and durable with solid nylon centres l Smooth and quiet running suited for heavy marking qualities. l Weld on Mounting plates available l For loads up to 300kg l Nylon wheels for hard wearing and non- warehouse and engineering requirements l and sealed ball bearings F Fixed P Swivel P-TB Swivel Total Brake IDN100/F 100 36 White Nylon 250kg Ball 128 F 114x100 85x75 IDN100/P 100 36 White Nylon 250kg Ball 128 S 114x100 85x75 IDN100/P-TB 100 36 White nylon 250kg Ball 128 TB 114x100 85x75 IDN125/P 125 36 White Nylon 300kg Ball 152 S 114x100 85x75 IDN125/P-TB 125 36 White Nylon 300kg Ball 152 TB 114x100 85x75 IDN125/F 125 36 White Nylon 300kg Ball 152 F 114x100 85x75 Wheel Wheel Overall Swivel Plate Bolt (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing IDN100/F IDN100/P-TB IDN125/P F P P-TB BRACKET KEY
35 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 Heavy Industrial Castors - Grey Wheels Features double ball bearing headrace with inner and outer bearing seals ensuring smooth swivelling action and long life l Rubber wheels for shock absorbing and l Weld on Mounting plates available l Strong and durable with polyprop centres and sealed ball bearings l Smooth and quiet running suited for heavy warehouse and engineering requirements l For loads up to 180kg non-marking qualities F Fixed P Swivel P-TB Swivel Total Brake IDR125/P 125 36 Grey Rubber 180kg Ball 152 S 114x100 85x75 IDR100/P-TB 100 36 Grey Rubber 150kg Ball 128 TB 114x100 85x75 IDR100/P 100 36 Grey Rubber 150kg Ball 128 S 114x100 85x75 IDR100/F 100 36 Grey Rubber 150kg Ball 128 F 114x100 85x75 IDR125/F 125 36 Grey Rubber 180kg Ball 152 F 114x100 85x75 IDR125/P-TB 125 36 Grey Rubber 180kg Ball 152 TB 114x100 85x75 Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) Wheel Wheel Overall Swivel Plate Bolt IDR100/F IDR100/P-TB IDR100/P F P P-TB BRACKET KEY
36 www.alliedindustrial.com.au IDU100/F IDU100/P-TB Heavy Industrial Castors IDU100/P Features double ball bearing headrace with inner and outer bearing seals ensuring smooth swivelling action and long life. - Orange Urethane Wheels l Weld on Mounting plates available l For loads up to 250kg Strong and durable with polyprop centres marking qualities and sealed ball bearings l Urethane wheels for hard wearing and nonl Smooth and quiet running suited for heavy warehouse and engineering requirements F Fixed P Swivel P-TB Swivel Total Brake F P P-TB IDU100/P 100 36 Urethane 200kg Ball 128 S 114x100 85x75 IDU125/P 125 36 Urethane 250kg Ball 152 S 114x100 85x75 IDU100/F 100 36 Urethane 200kg Ball 128 F 114x100 85x75 IDU100/P-TB 100 36 Urethane 200kg Ball 128 TB 114x100 85x75 IDU125/F 125 36 Urethane 250kg Ball 152 F 114x100 85x75 IDU125/P-TB 125 36 Urethane 250kg Ball 152 TB 114x100 85x75 Wheel Wheel Overall Swivel Plate Bolt (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing BRACKET KEY
37 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 F Fixed P Swivel P-TB Swivel Total Brake Wheel Wheel Overall Swivel Plate Bolt Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) Features double ball bearing headrace with outer seals ensuring smooth swivelling action and long life - Nylon Wheels l For loads up to 300kg equipment, workshops/warehouses and marking qualities l Strong and durable material handling equipment l Nylon wheels for hard wearing and nonl Smooth and quiet running suited for mobile AHN150/F AHN200/P-TB AHN150/P F P P-TB AHN200/F 200 50 White Nylon 300kg Plain 237 F 135x105 105x80 AHN150/P-TB 150 50 White Nylon 300kg Plain 190 TB 135x105 105x80 AHN200/P 200 50 White Nylon 300kg Plain 237 S 135x105 105x80 AHN150/F 150 50 White Nylon 300kg Plain 190 F 135x105 105x80 AHN150/P 150 50 White Nylon 300kg Plain 190 S 135x105 105x80 AHN200/P-TB 200 50 White Nylon 300kg Plain 237 TB 135x105 105x80 Heavy Industrial Castors BRACKET KEY
38 www.alliedindustrial.com.au F Fixed P Swivel P-TB Swivel Total Brake Wheel Wheel Overall Swivel Plate Bolt Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) - Blue Rubber Wheels Features double ball bearing headrace with outer seals ensuring smooth swivelling action and long life equipment, workshops/warehouses and l For loads up to 300kg l Rubber wheels for shock absorbing and non-marking qualities l Strong and durable with polyprop centres and ball bearings l Smooth and quiet running suited for mobile material handling equipment IHB125/F AHB200/P-TB AHB150/P F P P-TB IHB125/P-TB 125 50 Blue Rubber 250kg Ball 162 TB 137x105 105x80 AHB200/F 200 50 Blue Rubber 300kg Ball 237 F 135x105 105x80 IHB125/P 125 50 Blue Rubber 250kg Ball 162 S 137x105 105x80 AHB150/F 150 50 Blue Rubber 300kg Ball 190 F 135x105 105x80 IHB125/F 125 50 Blue Rubber 250kg Ball 162 F 137x105 105x80 AHB150/P 150 50 Blue Rubber 300kg Ball 190 S 135x105 105x80 AHB150/P-TB 150 50 Blue Rubber 300kg Ball 190 TB 135x105 105x80 AHB200/P 200 50 Blue Rubber 300kg Ball 237 S 135x105 105x80 AHB200/P-TB 200 50 Blue Rubber 300kg Ball 237 TB 135x105 105x80 Heavy Industrial Castors BRACKET KEY
39 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 Heavy Industrial Castors F Fixed P Swivel P-TB Swivel Total Brake Wheel Wheel Overall Swivel Plate Bolt Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) Features double ball bearing headrace with outer seals ensuring smooth swivelling action and long life - Urethane Wheels and ball bearings equipment, workshops/warehouses and l Urethane wheels for hard wearing and non- marking qualities l Strong and durable with polyprop centres l Smooth and quiet running suited for mobile l For loads up to 300kg material handling equipment IHU125/F AHU200/P-TB AHU150/P F P P-TB AHU200/P-TB 200 50 Red Urethane 300kg Ball 237 TB 135x105 105x80 IHU125/P 125 50 Red Urethane 250kg Ball 162 S 137x105 105x80 AHU200/F 200 50 Red Urethane 300kg Ball 237 F 135x105 105x80 IHU125/P-TB 125 50 Red Urethane 250kg Ball 162 TB 137x105 105x80 AHU150/F 150 50 Red Urethane 300kg Ball 190 F 135x105 105x80 AHU150/P 150 50 Red Urethane 300kg Ball 190 S 135x105 105x80 AHU150/P-TB 150 50 Red Urethane 300kg Ball 190 TB 135x105 105x80 IHU125/F 125 50 Red Urethane 250kg Ball 162 F 137x105 105x80 AHU200/P 200 50 Red Urethane 300kg Ball 237 S 135x105 105x80 BRACKET KEY
40 www.alliedindustrial.com.au F Fixed P Swivel P-TB Swivel Total Brake Wheel Wheel Overall Swivel Plate Bolt (mm) (mm) Material Castor Type (mm) Fixed (mm) (mm) Diameter Width Wheel Load per Bearing Height Total Brake Size Spacing Features double ball bearing headrace ensuring smooth swivelling action and long life - Urethane/Nylon Wheels l Strong and durable with sealed ball bearings mobile equipment, workshops/warehouses and material handling equipment l Smooth and quiet running suited for heavy l Urethane/Nylon wheels for hard wearing and non-marking qualities l For loads up to 600kg IPU35/P F IPN50/F P IPN75/P P-TB Low Profile Heavy Duty Castors P-TB IPN75/P-TB IPU35/P-TB 35 25 Urethane 100kg Ball 58 B 60x60 48x48 IPN50/P-TB 50 38 Cast Nylon 300kg Ball 79 B 84x84 64x64 IPN75/P-TB 75 50 Cast Nylon 600kg Ball 105 B 100x100 80x80 IPU35/P 35 25 Urethane 100kg Ball 58 S 60x60 48x48 IPN50/F 50 38 Cast Nylon 300kg Ball 79 F 84x84 64x64 IPN50/P 50 38 Cast Nylon 300kg Ball 79 S 84x84 64x64 IPN75/F 75 50 Cast Nylon 600kg Ball 105 F 100x100 80x80 IPN75/P 75 50 Cast Nylon 600kg Ball 105 S 100x100 80x80 BRACKET KEY
H Swivel H-TB Total Brake BRACKET KEY 41 Email sales@alliedindustrial.com.au | Phone 02 9912 5105 (mm) (mm) Material Castor Type (mm) Fixed Wheel Wheel Overall Swivel Bolt Diameter Width Wheel Load per Bearing Height Total Brake Hole Features double ball bearing headrace ensuring smooth swivelling action and long life - Urethane/Nylon Wheels l Strong and durable with sealed ball bearings l Urethane/Nylon wheels for hard wearing and l Smooth and quiet running suited for heavy mobile equipment, workshops/warehouses and material handling equipment l For loads up to 600kg non-marking qualities Low Profile Heavy Duty Castors IPN75/H-M16 75 50 Cast Nylon 600kg Ball 105 S M16 bolt IPN50/H-B-M16 50 38 Cast Nylon 300kg Ball 79 B M16 bolt IPU35/H-B 35 25 Urethane 100kg Ball 58 B 10 IPU35/H 35 25 Urethane 100kg Ball 58 S 10 IPN50/H-M16 50 38 Cast Nylon 300kg Ball 79 S M16 bolt IPN75/H-B-M16 75 50 Cast Nylon 600kg Ball 105 B M16 bolt IPU35/H IPN75/H-B-M16 IPN50/H-M16 H H H-TB
